Used YCM NXV 1020AM CNC Vertical Machining Center FANUC BT40

Loading carousel...

Product Highlight

Used YCM NXV 1020AM CNC vertical machining center manufactured by YCM in Taiwan. This CNC milling machine features a FANUC control system, BT40 spindle interface, 15,000 RPM spindle speed, and a 24-tool automatic tool changer. With large machining travels and rigid linear guideway construction, it is designed for precision machining of molds, mechanical components, and industrial parts. This second-hand YCM machining center offers an economical solution for manufacturers requiring reliable CNC production capacity.

Product Description

Used YCM NXV 1020AM CNC vertical machining center, manufactured in Taiwan. Equipped with FANUC control, BT40 spindle, 24-tool arm type ATC, and high-speed machining capability. A reliable second-hand CNC milling solution for precision mold, automotive, and general machining applications.

Product Specifications

Item	Specification
Machine Type	Used CNC Vertical Machining Center
Brand	YCM (Yeong Chin Machinery Industries)
Model	NXV 1020AM
Machine Origin	Taiwan
CNC Controller	FANUC 0i-MF / MXP-200FB+ system
Spindle Taper	BT40
Spindle Speed	15,000 RPM
Tool Magazine Capacity	24 Tools
Tool Change System	Arm Type Automatic Tool Changer (ATC)
X Axis Travel	1020 mm
Y Axis Travel	520 mm
Z Axis Travel	540 mm
Table Size	1120 × 520 mm
Guideway System	Three-axis linear guideway
Spindle Cooling	Equipped
Spindle Lubrication	Equipped
Coolant System	Equipped with coolant flushing system
Additional Features	Tool measurement system, dual screw chip conveyor, coolant through spindle preparation
Machine Condition	Used / Second-hand CNC Machine

Applications & Suitable Industries

Used YCM NXV 1020AM vertical machining center is suitable for precision machining applications requiring stability, speed, and accuracy.

Typical applications include:

Mold and die manufacturing
Automotive component machining
Aerospace parts processing
Precision mechanical parts production
Aluminum and steel component machining
Fixture and tooling production
Small and medium batch CNC machining
General engineering workshops

This second-hand CNC machining center is ideal for manufacturers looking to expand production capacity with a cost-effective alternative to purchasing a new machine.

FAQ

What controller does the YCM NXV 1020AM use?

The machine is equipped with a FANUC CNC control system, providing stable operation and compatibility with many industrial machining environments.

Can this used YCM machining center process molds and precision parts?

Yes. With BT40 spindle tooling, 15,000 RPM spindle speed, and a rigid vertical machining structure, it is suitable for mold making, precision components, and general CNC milling work.
