Used STUDER S33 CNC Cylindrical Grinder

Loading carousel...

Product Highlight

Used STUDER S33 is a Swiss-made CNC universal cylindrical grinder designed for high-precision machining of shafts, spindles and other cylindrical components. This used machine features FANUC CNC control, a 650 mm distance between centers and a 175 mm center height. Its combination of precision, flexible grinding capability and established STUDER engineering makes it suitable for toolrooms, precision machining companies and industrial production environments seeking a cost-effective alternative to purchasing new grinding equipment.

Product Description

Used STUDER S33 CNC universal cylindrical grinder made in Switzerland, equipped with FANUC CNC control and a 650 mm distance between centers. This pre-owned precision grinding machine was previously operated in a European factory and is offered in well-kept condition. With a center height of 175 mm, maximum workpiece weight of 150 kg and seller-reported grinding accuracy within the 1 μm range under suitable operating conditions, it is a strong option for precision shaft, spindle and cylindrical component grinding.

Technical Specifications

Specification	Details
Brand	STUDER
Model	S33
Machine Type	CNC Universal Cylindrical Grinding Machine
Condition	Used / Pre-Owned
Country of Origin	Switzerland
CNC Control	FANUC
Distance Between Centers	650 mm
Center Height	175 mm
S33 Series Center Distance Options	400 / 650 / 1000 / 1600 mm
Maximum Workpiece Diameter	349 mm
Maximum Workpiece Weight	150 kg
Maximum Spindle Speed	3,200 rpm
Maximum Grinding Wheel Diameter	508 mm
Maximum Grinding Wheel Width	80 mm
X-Axis Maximum Travel	370 mm
X-Axis Maximum Rapid Speed	15,000 mm/min
Z-Axis Travel	Approx. 800 mm for 650 mm center-distance configuration
Z-Axis Maximum Rapid Speed	20,000 mm/min
Maximum Spindle Power	8 kW
B-Axis Swivel Range	255°
C-Axis	Continuous / infinitely programmable rotation depending on configuration
Reported Grinding Accuracy	Within 1 μm range under suitable setup and operating conditions

Specification Note:

Technical data may vary according to machine configuration, grinding head, accessories and original factory options. Final specifications should be confirmed before purchase.

STUDER's official S33 information confirms key family specifications including a 175 mm center height, maximum workpiece weight of 150 kg, maximum workpiece diameter of 349 mm, 508 mm grinding wheel diameter, 80 mm wheel width and 255° B-axis swivel range.

Applications & Suitable Industries

Used STUDER S33 CNC cylindrical grinder is designed for precision cylindrical grinding of small and medium-sized components and is suitable for individual parts, small batches and production environments.

Typical applications include:

Precision shaft grinding – motor shafts, transmission shafts, pump shafts and stepped shafts.
Spindle manufacturing – machine tool spindles and other high-precision rotating components.
Bearing component grinding – bearing journals, seating surfaces and precision cylindrical sections.
Automotive components – transmission parts, drive components and precision shaft-type parts.
Aerospace components – high-precision cylindrical parts requiring tight dimensional control.
Hydraulic components – piston rods, valve components and precision cylindrical surfaces.
Tool and mold manufacturing – precision tooling, arbors, mandrels and related components.
General precision engineering – external cylindrical, shoulder and complex cylindrical grinding operations.

Its universal grinding configuration makes the STUDER S33 particularly suitable for manufacturers that process multiple part types rather than relying on a dedicated grinder for only one component.

STUDER describes the S33 as suitable for individual, small-batch and volume production, with complex workpiece geometries capable of being processed in a single clamping depending on machine configuration.

FAQ

What is the distance between centers of this used STUDER S33?

This machine is configured with a 650 mm distance between centers and a center height of 175 mm, making it suitable for a wide range of precision shaft and cylindrical workpieces.

What CNC control does this STUDER S33 use?

The machine is equipped with a FANUC CNC control system, providing programmable control for precision cylindrical grinding operations and production setups.

What accuracy can this used STUDER S33 cylindrical grinder achieve?

The seller reports grinding accuracy within the 1 μm range under suitable machine setup, tooling, dressing, workholding and environmental conditions. Actual production accuracy should be verified according to the buyer's workpiece and process requirements.

What parts can be produced on a STUDER S33 CNC grinder?

The STUDER S33 is commonly suitable for precision shafts, spindles, bearing journals, hydraulic components, automotive transmission parts, tooling and other cylindrical workpieces requiring accurate external grinding. Depending on its installed grinding head and options, additional grinding operations may also be possible.
