Product Highlight

Used SHIGIYA GP-30B 150H is a Japanese hydraulic cylindrical grinder suitable for precision OD grinding of long shafts, rollers and cylindrical components. Its long grinding capacity, hydraulic table feed, MT4 center system and conventional operation make it a practical choice for machining, maintenance and precision grinding workshops.

Product Description

Used SHIGIYA GP-30B 150H cylindrical grinder from Japan is designed for precision external cylindrical grinding of long shafts, rollers, spindles and similar components. With a 1500 mm usable grinding length, hydraulic table movement, MT4 centers and a grinding wheel diameter up to 405 mm, it is a practical option for toolrooms, repair workshops and precision machining facilities requiring reliable long-workpiece OD grinding.

SHIGIYA describes the GP-30B H series as a plain cylindrical grinder with manual wheel feed and hydraulic table feed. The manufacturer lists a 300 mm swing over table and a maximum grinding diameter of 220 mm for the GP-30B H configuration.

Technical Specifications

Specification	Details
Brand	SHIGIYA
Model	GP-30B 150H
Machine Type	Used Hydraulic Cylindrical Grinder
Grinder Type	Plain / External Cylindrical Grinder
Country of Origin	Japan
Grinding Length	1500 mm
Manufacturer Series Center Distance	1600 mm
Manufacturer Series Swing Over Table	Ø300 mm
Manufacturer Series Max. Grinding Diameter	Ø220 mm
Grinding Wheel Diameter	Ø320–405 mm
Grinding Wheel Width	25–75 mm
Grinding Wheel Bore	Ø152.4 mm
Table Swivel Angle	+7° / -1°
Workhead Swivel Angle	+20° / -80°
Headstock / Tailstock Taper	MT4
Table Width	200 mm
Supplied Workpiece Weight Reference	20 kg
Manufacturer Series Load Between Centers	Up to 130 kg
Maximum Wheel Peripheral Speed	Approx. 2000 m/min / 33 m/s
Table Feed	Hydraulic
Wheel Feed	Manual
Position Display	Digital Readout
Condition	Used / Pre-owned

Specification note: the supplied machine data states a 1500 mm grinding length, while SHIGIYA's manufacturer reference for the GP-30B 150H lists a 1600 mm distance between centers. These are not necessarily contradictory: usable grinding length and nominal center distance can differ. SHIGIYA's published standard wheel specification is Ø405 × 50 × Ø152.4 mm with a 33 m/s peripheral speed.

For quotation purposes, the actual configuration should be confirmed before shipment because tooling, electrical specification and optional equipment can vary between individual used machines.

Applications & Suitable Workpieces

Used SHIGIYA GP-30B 150H OD cylindrical grinder is especially suitable for workshops that need to grind relatively long cylindrical components while maintaining controlled diameter, roundness and surface finish.

Typical applications include:

Long shaft and transmission shaft OD grinding
Motor shaft and spindle grinding
Hydraulic rod and piston rod finishing
Roller and cylindrical component grinding
Bearing journal and stepped shaft finishing
Machine-tool spindle repair and reconditioning
Toolroom and maintenance grinding
Low-to-medium volume precision component production
Automotive, machinery, mold, hydraulic and general engineering applications

Its long grinding capacity makes it particularly relevant for buyers searching for terms such as used cylindrical grinder, used Japanese cylindrical grinding machine, SHIGIYA grinder for sale, 1500mm cylindrical grinder, long shaft grinding machine, and used OD grinder.

FAQ

Is the SHIGIYA GP-30B 150H a CNC cylindrical grinder?

No. The GP-30B 150H is a conventional hydraulic cylindrical grinder rather than a full CNC grinder. SHIGIYA identifies the H version as having manual grinding-wheel feed combined with hydraulic table feed, making it suitable for operators who prefer straightforward conventional grinding control.

What is the grinding length of this used SHIGIYA GP-30B 150H?

The supplied machine specification gives a 1500 mm usable grinding length. SHIGIYA's series specification lists the GP-30B 150H with a nominal 1600 mm distance between centers, so buyers should distinguish between center distance and actual usable grinding length.

What grinding wheel size can the SHIGIYA GP-30B 150H use?

The supplied configuration accepts approximately Ø320–405 mm grinding wheels, with widths from 25 to 75 mm and a Ø152.4 mm bore. SHIGIYA's standard GP-30B specification lists a Ø405 × 50 × Ø152.4 mm wheel and a maximum peripheral speed of 33 m/s.

What kind of parts can I grind with this machine?

This machine is well suited to long shafts, rollers, spindles, hydraulic rods, bearing journals and other precision cylindrical components. If you send us your workpiece diameter, length, material and required tolerance, the machine's suitability can be checked against your application.
