Used MICRON MIG-10U CNC Internal Grinder Japan FANUC

Loading carousel...

Product Highlight

Used MICRON MIG-10U is a high precision CNC internal grinding machine manufactured by MICRON Machinery Co., Ltd. in Japan. Equipped with a FANUC CNC system, this compact grinder is designed for ultra-precision internal grinding of small diameter components. With a grinding spindle speed up to 150,000 rpm and micron-level positioning capability, it is suitable for industries requiring high accuracy and consistent machining performance.

Product Description

Used MICRON MIG-10U CNC internal grinding machine from Japan, equipped with FANUC control system. Designed for ultra-precision bore grinding, this machine delivers high accuracy and stable performance for demanding precision machining applications.

Product Specifications

Item	Specification
Machine Type	Used CNC Internal Grinding Machine
Brand	MICRON
Model	MIG-10U
Manufacturer	Micron Machinery Co., Ltd.
Country of Origin	Japan
Control System	FANUC CNC
Machine Condition	Used / Pre-owned
Grinding Type	Internal Cylindrical Grinding
Maximum Grinding Diameter	Internal diameter: up to Ø10 mm
External Diameter Capacity	Up to Ø20 mm
Minimum Resolution	0.0001 mm
Wheel Speed	Up to 2700 m/s
Work Spindle Speed	0 - 4000 rpm
Grinding Spindle Speed	Up to 150,000 rpm
Positioning Accuracy	Micron-level precision control
Processing Capability	Roundness within 0.2 μm
Floor Space	Approx. 1600 × 1400 mm
Machine Weight	Approx. 2200 kg
Voltage	200V
Phase	3 Phase
Frequency	50Hz
Manufacturing Date	2006/07
Serial Number	5689

Application & Industry

Used MICRON MIG-10U internal grinding machine is suitable for high-precision machining applications requiring extremely accurate small-diameter grinding.

Typical applications include:

Precision bearing component manufacturing
Hydraulic and pneumatic parts machining
Automotive precision components
Semiconductor equipment parts
Medical device components
Aerospace precision parts
Small precision shafts and sleeves
Mold and tooling component processing

This CNC internal grinder is especially suitable for manufacturers requiring micron-level bore accuracy, fine surface finish, and stable repeat production capability.

FAQ

What type of parts can the MICRON MIG-10U process?

The machine is mainly designed for precision internal grinding of small holes, sleeves, bearings, shafts, and other components requiring high dimensional accuracy.
